NXP® i.MX 8コンピューターオンモジュール

Apalis iMX8

ハイライト

最大8つのArmコアで最高の性能と効率を発揮

Apalis iMX8は、最新のNXP® i.MX 8 SoCを搭載した小型フォームファクタのシステムオンモジュールです。最高の性能を発揮するi.MX 8 SoC、i.MX 8QuadMxには、2つのCortex-A72および2つのCortex-A53アプリケーションプロセッサーコアと2つのFPU対応Cortex-M4Fマイクロコントローラコアが搭載されています。最新Cortex-Aコアは、Arm8 64ビット命令セットをサポートします。


ビジョンとメディア処理のアプリケーションに最適な構成

Apalis iMX8 SoMは、最先端のコンピュータービジョンシステムの構築に適しています。高性能のデュアルGC7000 GPUが、豊富な機能を備えた複雑なグラフィカルユーザーインターフェイスと複数の独立型ディスプレイをサポートします。Toradexは、The Qt Company、Crank Softwareやそのほか企業と提携して最適化されたUIフレームワークを提供しており、製品の市場投入を加速します。


高度な安全とセキュリティ機能

ハードウェアの仮想化、セキュアブート、最新の暗号化に対応しており、安全でセキュアなシステムの構築が可能です。SafeAssure® のフェイルオーバーに対応するディスプレイコントローラにより、重要なディスプレイに常に適切なコンテンツを表示させることができます。i.MX 8 SoCは、28nmの高度なFDSOIシリコンプロセス技術に基づいており、MTBFを改善し、ソフトエラー率を削減します。


ハードリアルタイム対応

ヘテロジニアマルチコアのアーキテクチャでは、Cortex M4/M7プロセッサーにハードリアルタイムの重要なタスクをオフロードすることで極めて低いレイテンシを実現できます。Toradexが提供するツールとFreeRTOSにより、開発も簡素化されます。非対称型マルチコアのアーキテクチャは、接続低電力モードまたはセキュリティ向上のために活用することもできます。


リモートアップデートとフリートモニタリングのためのTorizon

弊社のCPUモジュールは、緊密に統合されたTorizonプラットフォームで利用でき、製品の開発とメンテナンスを加速します。 いくつかの重要な機能には、安全性と信頼性の高いリモート更新、フリート監視、リモートアクセスが含まれます。


堅牢な作りと高い信頼性

モジュールには、振動およびEMI/EMCの環境テスト報告書が付随しているので、安心してご利用いただけます。非常に信頼性の高いeMMCフラッシュメモリを採用しており、さらにToradexのFlash Analyticsといったツールにより、非常にシンプルな方法でフラッシュメモリの疲弊度を監視できます。


Toradex Apalisコンピューターオンモジュールファミリー

Apallis iMX8は他のApalisファミリーのCOMとピン互換性があります。(*)
これにより、既存のApalisベースの製品から容易に拡張し、新しいApalis iMX8に移行することができます。Toradexの Apalis Carrier Board は全てのApalis iMX8と互換性があります。
豊富な製品マニュアル、開発者サポート、サービスパートナー、サードパーティ製のCarrier Boardが、当社の強力なエコシステムを構築しています。
(*) Apalis iMX8開発者向けページをご覧になり、完全な互換性をご確認ください。


Toradex Apalis iMX8システムオンモジュール - 詳細

このビデオでは、新しく発売されたApalis iMX8システムオンモジュールの主な機能について紹介し、モジュールの使用方法について説明します。

オペレーティングシステム

Toradexは、NXP i.MX 8プロセッサー搭載Apalis iMX8 SoM上で組み込みLinuxとFreeRTOSを無償でサポートし、その保守管理を行います。これにより、システムデザイナーは、OSや低レベルのデバイスドライバではなく実際のアプリケーションに重点的に取り組むことができます。そのほかAndroidやQNXなどのOSは、Toradexのパートナー企業がサポートしています。

Android

Toradexのサービスパートナー企業Kyneticsが、Apalis iMX8上でAndroidをサポートしています。評価版BSPは、Toradex Easy Installerフィードで無償のバイナリインストーラーとして。


QNX

QNXは、マイクロカーネルベースのOSで、安全性が重要な組み込みシステムを主なターゲットとしています。Apalis iMX8用の評価イメージは、BlackBerry/QNXから直接提供されています。



エコシステム

リスクとエンジニアリング経費を抑え、短時間で市場に製品を投入するために必要なのは、安定したオペレーティングシステム/BSPを搭載したシステムオンモジュールだけではありません。Toradexは、お客様の製品開発を容易にするため、広範なパートナー企業と提携しています。ここではその一部を紹介しています。ほかの企業を探すには開発者向けページで検索し、パートナーネットワークを参照してください。


Toradex Easy Installer

Toradex Easy Installerを使えば、OSをワンクリックでインストールできます。工場出荷時に事前インストールされているので、必要な作業はApalis iMX8に電源を入れてOSを選択するだけです。

詳細を見る

使いやすいリッチなグラフィカルユーザーインターフェイス

Apalis iMX8は高性能グラフィックスを提供します。Toradexは、GUIの大手プロバイダーと提携することで、開発プロセスの簡素化とハードウェアリソースの最も効果的な利用を可能にしています。

Qtフレームワーク

Qtは、Toradex Easy Installerで入手可能で、さらにTorizon用のDebianコンテナとしても用意されており、あらゆる組み込みデバイスで簡単にQtを利用することができます。

Qtの利用方法 オンデマンドウェビナー:NXP i.MX 8でQtプロジェクトを始めましょう!

Crank Storyboard

Crank Storyboardは、高性能組み込みアプリの迅速な開発を可能にするGUIの設計、開発ツールです。Torizonで使用開始時のシームレスなエクスペリエンスを提供します。

Crank Storyboardの利用方法

DiSTI GL Studio

Apalis iMX8に最も適しているのは安全と信頼性が重要なアプリケーションですが、DiSTIのGL Studioもまた、そうしたエリアに焦点を合わせています。

DiSTIGL Studioの利用方法

TotalCross

TotalCrossは、GUI作成のためのオープンソースSDKで、JavaまたはKotlinを使用した優れたアプリの作成が可能になります。

TotalCrossの利用方法

エッジのAI

Apalis iMX8は、i.MX 8 SoCの最高性能、複数のARMv8 64ビットコアとデュアルGPUを備えており、機械学習やコンピュータービジョンアプリケーションに最適なプラットフォームです。 低レイテンシと高信頼性の要件は、エッジコンピューティングの成長を加速している利点です。

Toradexはパートナー企業と協力することで、お客様がAIやコンピュータービジョン、エッジコンピューティングの最新テクノロジーを簡単に活用できるよう、取り組みを進めています。

DeepView™ 2機械学習アルゴリズム

DeepView™ 2は、Apalis iMX8のCPUとGPUを活用してエッジの機械学習アルゴリズムの最適化を簡素化します。

アップデートを入手

AWS IoT GreengrassとSageMaker Neo

AWS IoT GreengrassやSageMaker Neoなど、AWSはエッジのAIに役立つ広範なサービスを提供しています。現在AWSとNXP、Toradexは緊密なコラボレーションを行っています。

AWS SageMaker Neoの利用方法

Alvium MIPI CSI-2産業グレードカメラ

Alviumファミリーの新しいMIPI CSI-2産業グレードカメラは、ビジョンアプリケーションに最適です。Toradexとの統合について詳しくは、「AI at the Edge, Pasta Detection Demo with AWS(エッジのAI、AWSを使ったパスタ検出のデモ)」をご覧ください。

Apalis iMX8組み込みビジョンキット

Antmicro Apalisスマートビジョンキット

Antmicroは、Apalis iMX8向けに、既製のデュアルカメラMIPI CSI-2キャリアボード、ハードウェアおよびソフトウェアエンジニアリングサービスを提供し、Toradex製品の機能を拡張します。

Antmicroビジョンキット


産業オートメーション

CODESYS PLC IEC 61131-3

堅牢な作りと高い性能を備えたApalis iMX8は、要求の厳しい産業オートメーションのシナリオに最適です。CODESYSは、長年の実績が豊富なソフトウェアソリューションによって簡単にカスタマイズできるPLCの開発を可能にします。

TorizonにおけるCODESYSの利用方法

Matrikon OPC UA

OPC UAは、産業オートメーションに広く利用されている標準技術です。Matrikonによるスタックは、信頼性、安全性に優れ、プラットフォームに依存しない実装となっており、Apalis iMX8に最適です。

BE.servicesとの共同オンラインセミナーを視聴

リアルタイム、安全性、低消費電力のためのヘテロジニアスマルチコア処理(HMP)

Apalis iMX8には、266MHzの高速なクロック速度を持つ2つのCortex-M4コアが搭載されています。M4のレイテンシはマイクロ秒単位なので、これらのコアは、Linuxからハードリアルタイムアプリケーションをオフロードするのに最適です。
そのほかの一般的な使用例としては、アクティブ低電力モードがあります。このモードでは、機能安全のためメインコアの電源をオフにし、M4コアが、i.MX 8内のECC保護に対応した密結合メモリからSafeRTOSなどのRTOSを実行します。
Toradexは、Visual Studio Codeとの統合などの開発により、お客様がM4コアに用意にアクセスできるよう尽力しています。

quote
"「全電気仕様のRimac C-Twoハイパーカーで導入された、次世代Rimacインフォテイメントシステムには、Toradex Apalis i.MX 8QuadMax SoMベースのマルチスクリーンが統合されたコックピットが搭載されています。パワフルなA72コアとA53コアのおかげで、リッチなグラフィックスと総合的なマルチメディア体験を実現させると同時に、M4コアとソフトウェアドメイン分離の機能を活用することで、Rimac社の車両およびそのほかのOEM向けにASIL-Bに準拠したソリューションを開発できます。
Toradexとの長期的な協力関係により、以前のApalis i.MX 6ベースのインフォテイメントから新しい i.MX 8ベースのインフォテイメントへと容易にアップグレードできる柔軟性を備えた、総合的なコードベースを開発することができました。」 "
Tomislav Lugarić,
Rimac Automobili d.o.o.、ICUソフトウェアマネージャー
quote

特徴

High speed dual-band Wi-Fi
- 802.11ac 2x2 MU-MIMO
Bluetooth 5

Dual Arm Cortex -A72 @ 1.6GHz
Quad Arm Cortex -A53 @ 1.26GHz
Dual Arm Cortex M4F @ 266MHz
Dual Vivante GC7000 GPU

Gigabit Ethernet Transceiver

Up to 8GB LPDDR4 RAM

Industrial-grade flash memory
Up to 32GB eMMC

Integrated PMIC
Single 3.3V power supply



Apalis iMX8 QuadMax 8GB Wi-Fi / Bluetooth IT

PN: 0067
ご購入


Apalis iMX8 QuadMax 4GB Wi-Fi / Bluetooth IT

PN: 0037
ご購入


Apalis iMX8 QuadMax 4GB IT

PN: 0047
ご購入


Apalis iMX8 QuadPlus 2GB Wi-Fi / Bluetooth

PN: 0048
ご購入


Apalis iMX8 QuadPlus 2GB

PN: 0049
  •
ご購入


カスタム製品について

本モジュールのBTOにご興味がございましたら、お問い合わせしてください。
CPU Name
CPU Type
Microcontroller
CPU Clock
Floating Point Unit
NEON
L1 Instruction Cache
L1 Data Cache
L2 Cache
NXP® i.MX 8QuadMax
2x Arm Cortex™-A72
4x Arm Cortex™-A53
2x Arm Cortex™-M4F
1.6 GHz (A72)
1.26 GHz (A53)
266 MHz (M4)
Yes
Yes
48KB (A72), 32KB (A53), 16KB (M4)
32KB (A72), 32KB (A53), 16KB (M4)
1MB (A72), 1MB (A53)
NXP® i.MX 8QuadMax
2x Arm Cortex™-A72
4x Arm Cortex™-A53
2x Arm Cortex™-M4F
1.6 GHz (A72)
1.26 GHz (A53)
266 MHz (M4)
Yes
Yes
48KB (A72), 32KB (A53), 16KB (M4)
32KB (A72), 32KB (A53), 16KB (M4)
1MB (A72), 1MB (A53)
NXP® i.MX 8QuadMax
2x Arm Cortex™-A72
4x Arm Cortex™-A53
2x Arm Cortex™-M4F
1.6 GHz (A72)
1.26 GHz (A53)
266 MHz (M4)
Yes
Yes
48KB (A72), 32KB (A53), 16KB (M4)
32KB (A72), 32KB (A53), 16KB (M4)
1MB (A72), 1MB (A53)
NXP® i.MX 8QuadPlus
1x Arm Cortex™-A72
4x Arm Cortex™-A53
2x Arm Cortex™-M4F
1.6 GHz (A72)
1.26 GHz (A53)
266 MHz (M4)
Yes
Yes
48KB (A72), 32KB (A53), 16KB (M4)
32KB (A72), 32KB (A53), 16KB (M4)
1MB (A72), 1MB (A53)
NXP® i.MX 8QuadPlus
1x Arm Cortex™-A72
4x Arm Cortex™-A53
2x Arm Cortex™-M4F
1.6 GHz (A72)
1.26 GHz (A53)
266 MHz (M4)
Yes
Yes
48KB (A72), 32KB (A53), 16KB (M4)
32KB (A72), 32KB (A53), 16KB (M4)
1MB (A72), 1MB (A53)
NXP® i.MX 8 Series

NXP® i.MX 8QuadMax (i.MX 8QM), i.MX 8QuadPlus (i.MX 8QP), i.MX 8DualMax (i.MX 8DM)

RAM
Flash
8GB LPDDR4 (64 bit)
32GB eMMC
4GB LPDDR4 (64 Bit)
32GB eMMC
4GB LPDDR4 (64 Bit)
32GB eMMC
2GB LPDDR4 (64 Bit)
32GB eMMC
2GB LPDDR4 (64 Bit)
32GB eMMC
USB 3.0
USB 2.0
Ethernet
Wi-Fi
Bluetooth
PCIe
I2C
SPI
UART
IrDA
PWM
GPIO
Analog Input
Serial ATA
SDIO/SD/MMC
CAN
JTAG
1x Host
2x Host / 1x OTG
Gigabit with AVB (+2nd RGMII)
2.4/5 GHz Dual Band 2x2 Wi-Fi 5 (802.11ac)
Bluetooth 5.3
2 (x1 Gen 3)
7x
4x
7x
1x
8x
up to 133
8x
1x (SATA-III)
1x 8 Bit, 1x 4 Bit
3x (CAN FD)
1x
1x Host
2x Host / 1x OTG
Gigabit with AVB (+2nd RGMII)
2.4/5 GHz Dual Band 2x2 Wi-Fi 5 (802.11ac)
Bluetooth 5.3
2 (x1 Gen 3)
7x
4x
7x
1x
8x
up to 133
8x
1x (SATA-III)
1x 8 Bit, 1x 4 Bit
3x (CAN FD)
1x
1x Host
2x Host / 1x OTG
Gigabit with AVB (+2nd RGMII)
2 (x1 Gen 3)
7x
4x
7x
1x
8x
up to 133
8x
1x (SATA-III)
1x 8 Bit, 1x 4 Bit
3x (CAN FD)
1x
1x Host
2x Host / 1x OTG
Gigabit with AVB (+2nd RGMII)
2.4/5 GHz Dual Band 2x2 Wi-Fi 5 (802.11ac)
Bluetooth 5.3
2 (x1 Gen 3)
7x
4x
7x
1x
8x
up to 133
8x
1x (SATA-III)
1x 8 Bit, 1x 4 Bit
3x (CAN FD)
1x
1x Host
2x Host / 1x OTG
Gigabit with AVB (+2nd RGMII)
2 (x1 Gen 3)
7x
4x
7x
1x
8x
up to 133
8x
1x (SATA-III)
1x 8 Bit, 1x 4 Bit
3x (CAN FD)
1x
Display Controller
Graphics Controller
Video Decoder
Video Encoder
Display Serial Interface
LVDS
HDMI
Digital Audio
S/PDIF In / Out
2D Acceleration
3D Acceleration
Display Port
Resistive Touch
Camera Serial Interface
Analog Audio Line in
Analog Audio Mic in
Analog Audio Headphone out
Quad, Independent
Dual Vivante GC7000 XSVX
Yes
Yes
1x single lane MIPI DSI
3x 1366 x 768 x 24bpp Single / 1x 1920 x 1200 x 24bpp Dual + 1x 1366 x 768 x 24bpp Single
4K UltraHD (V2.0a, 2160p)
3x AC97 or
3x I2S,
1x ESAI
1x / 1x
Yes
Yes
1x eDP 1.4 or 1x DP 1.3
4-wire
2x Quad Lane MIPI CSI-2
1x (Stereo)
1x (Mono)
1x (Stereo)
Quad, Independent
Dual Vivante GC7000 XSVX
Yes
Yes
1x single lane MIPI DSI
3x 1366 x 768 x 24bpp Single / 1x 1920 x 1200 x 24bpp Dual + 1x 1366 x 768 x 24bpp Single
4K UltraHD (V2.0a, 2160p)
3x AC97 or
3x I2S,
1x ESAI
1x / 1x
Yes
Yes
1x eDP 1.4 or 1x DP 1.3
4-wire
2x Quad Lane MIPI CSI-2
1x (Stereo)
1x (Mono)
1x (Stereo)
Quad, Independent
Dual Vivante GC7000 XSVX
Yes
Yes
1x single lane MIPI DSI
3x 1366 x 768 x 24bpp Single / 1x 1920 x 1200 x 24bpp Dual + 1x 1366 x 768 x 24bpp Single
4K UltraHD (V2.0a, 2160p)
3x AC97 or
3x I2S,
1x ESAI
1x / 1x
Yes
Yes
1x eDP 1.4 or 1x DP 1.3
4-wire
2x Quad Lane MIPI CSI-2
1x (Stereo)
1x (Mono)
1x (Stereo)
Quad, Independent
Dual Vivante GC7000Lite XSVX
Yes
Yes
1x single lane MIPI DSI
3x 1366 x 768 x 24bpp Single / 1x 1920 x 1200 x 24bpp Dual + 1x 1366 x 768 x 24bpp Single
4K UltraHD (V2.0a, 2160p)
3x AC97 or
3x I2S,
1x ESAI
1x / 1x
Yes
Yes
1x eDP 1.4 or 1x DP 1.3
4-wire
2x Quad Lane MIPI CSI-2
1x (Stereo)
1x (Mono)
1x (Stereo)
Quad, Independent
Dual Vivante GC7000Lite XSVX
Yes
Yes
1x single lane MIPI DSI
3x 1366 x 768 x 24bpp Single / 1x 1920 x 1200 x 24bpp Dual + 1x 1366 x 768 x 24bpp Single
4K UltraHD (V2.0a, 2160p)
3x AC97 or
3x I2S,
1x ESAI
1x / 1x
Yes
Yes
1x eDP 1.4 or 1x DP 1.3
4-wire
2x Quad Lane MIPI CSI-2
1x (Stereo)
1x (Mono)
1x (Stereo)




Preinstalled OS
QNX
FreeRTOS
Supported
Supported
Supported by third party
Supported
Supported
Supported by third party
Supported
Supported
Supported by third party
Supported
Supported
Supported by third party
Supported
Supported
Supported by third party
Main Operating System
Microcontroller Operating System
Size
Temperature
Shock / Vibration
Power Dissipation
82.0 x 45.0 x 6.0 mm
-40° to 85° C(1)
Approx. 3.7W - 19.2W
82.0 x 45.0 x 6.0 mm
-40° to 85° C(1)
Approx. 3.8W - 15.5W
82.0 x 45.0 x 6.0 mm
-40° to 85° C
Approx. 4.5W - 14.6W
82.0 x 45.0 x 6.0 mm
-25° to 85° C
Approx. 3.5W - 16.0W
82.0 x 45.0 x 6.0 mm
-25° to 85° C
Approx. 3.4W - 14.8W
使用目的
価格
確保供給期間
For End Products
1-99 : $375.00
100-249 : $360.00
250-499 : $337.50
500-999 : $322.50
>999 : RFQ
2034+
For End Products
1-99 : $324.85
100-249 : $311.85
250-499 : $292.35
500-999 : $279.35
>999 : RFQ
2034+
For End Products
1-99 : $299.90
100-249 : $287.90
250-499 : $269.90
500-999 : $257.90
>999 : RFQ
2034+
For End Products
1-99 : $268.75
100-249 : $258.00
250-499 : $241.90
500-999 : $231.15
>999 : RFQ
2034+
For End Products
1-99 : $243.45
100-249 : $233.75
250-499 : $219.15
500-999 : $209.40
>999 : RFQ
2034+

The power consumption is subject to variation, depending on the situation. Our estimation of the minimum and maximum power consumption is based on the lowest idle power consumption and the highest power consumption values during maximum load. Refer our developer article for more information.


(1) The Wi-Fi/Bluetooth module featured on the SoM is rated for an operating temperature range of -30°C to +85°C. As this component is not deemed boot-critical, the SoM is still listed as an industrial temperature range product.

キャリアボード

キャリアボードは、必要な信号および電力をCoMに提供します。また、USB、イーサネット、UART、HDMIなど、アプリケーション固有の接続性とマルチメディアインターフェイスが搭載されます。

詳細を見る

Ixora キャリアボード

データシート

Apalis 評価ボード

データシート

Apalis Partner Carrier Boards

Supported Modules
USB 3.0
USB 2.0
Ethernet
PCIe
I2C
SPI
UART
IrDA
PWM
GPIO
Analog Input
Serial ATA
SDIO/SD/MMC
CAN
JTAG
Entire Apalis Family
2x Host
1x Host / 1x OTG
Gigabit
1x (Mini PCIe)
2x
1x
3x RS232
4x
up to 40
4x
1x mSATA
1x 4 Bit (microSD)
2x
Entire Apalis Family
1x Host, 1x OTG
4x Host
Gigabit
2x 1 slot / 1x (Mini PCIe)
3x
2x
2x RS232, 1x RS422/485
1x
4x
up to 135
4x
1x / 1x mSATA (shared)
2x 4 Bit
2x
Yes
Entire Apalis Family
up to 1x Host / 1x OTG
up to 4x Host
up to 11x 10/100/1000 MBit
up to 2x (Mini PCIe)
up to 2x I2C
up to 2x SPI
up to 8x RS-232/422/485
up to 4x PWM
up to 16x
up to 4x Analog Input
up to 1x mSATA
up to 1x SD/MMC 4-Bit
Up to 2x
Switches
LEDs
2x
8x
8x
LVDS
HDMI
Digital Audio
S/PDIF In / Out
VGA
RGB
Capacitive Touch Interface
Resistive Touch
Camera Parallel Interface
Camera Serial Interface
Analog Audio Line in
Analog Audio Mic in
Analog Audio Headphone out
1x Dual Channel
1x
1x / 1x
1x (24 Bit)
Yes
4/5-wire
1x 10 Bit
1x Quad Lane MIPI CSI-2
1x (Stereo)
1x (Mono)
1x (Stereo)
1x Dual Channel
1x (Through DVI-I connector)
7.1 Channel HD Audio Codec (incl. analogue connectors)
1x (Out also on TOSLINK)
1x
1x (24 Bit)
4/5-wire
1x 8/10/12 Bit
On Mezzanine
1x (Stereo)
1x (Mono)
1x (Stereo)
1x Dual Channel
1x
1x / 1x
1x
up to 4/5-wire
up to 3 MIPI CSI-2
1x (Stereo)
1x (Mono)
1x (Stereo)
Type Specific Board Connector
USB-to-RS232 Transceiver
RTC on Board
Altium CAE Data Freely Available
1x
Yes
Yes
1x
1x
Yes
1x
Supply Voltage
On-Board Power Supplies
Size
Temperature
7-27V DC
5V 6A
3.3V 8A
125 x 90 mm
-20° to 85° C
7-27V DC
5V 5A
3.3V 5A
250 x 250 mm
5 - 36V DC
-40° to 85° C
使用目的
価格
確保供給期間
For End Products
1-99 : $131.25
100-249 : $126.00
250-499 : $118.15
500-999 : $112.90
>999 : RFQ
2034+
For Evaluation/Development
1 : $325.00

アクセサリー

Toradexは、最終製品で直接利用可能な既製アクセサリを提供しています。いくつかのアクセサリでは、組み立て図面、回路図やAltiumプロジェクトを含む設計ファイルが用意されています。
Toradexは、Toradexウェブショップに掲載された周辺機器の検証を行い、カメラ、モデム、ディスプレイ、センサなどのベンダーと直接協力し、Toradex SoMとの統合ができるだけ容易になるようにしています。

詳しくは、Developer Centerを参照してください。
Apalis Heatsink Type 4
  • Compatible with Apalis iMX8
  • Easily mounted to the Apalis Carrier Boards by means of 4 screws
  • Additional threaded holes available for attaching fan to the carrier board
Apalis Heatsink Fan
  • Compatible with Apalis Evaluation Board and Ixora Carrier Board
Capacitive Touch Display 10.1" LVDS
  • LVDS cable (250mm) and 10 pin FFC cable (250mm) to connect it with a Carrier Board
キャリアボードアクセサリキット
  • Power Adapter: 12VDC 30W with international plugs
  • Compatible with: Apalis Evaluation Board, Ixora Carrier Board, Colibri Evaluation Board, Iris Carrier Board, Verdin Development Board, Dahlia Carrier Board
PCB Antenna Unictron AA222 MHF4 100mm
  • Cable length: 100mm
  • Frequency bands: 2.4 GHz and 5 GHz (dual-band)
  • Manufacturer: Unictron
  • Reference: AA222 (H2B1PD1A1C385L)
Chang Hong DA-2458-02 Dual-Band Wi-Fi/Bluetooth Dipole Antenna RP-SMA
  • Frequency bands: 2.4 GHz and 5 GHz (dual-band)
  • Manufacturer: Chang Hong
  • Reference: DA-2458-02
Pigtail Antenna Cable MHF4 to RP-SMA 100mm and 200mm
  • Cable length: 200mm
  • Suitable for outdoor-usage (IP67)
CSI Camera Set 5MP Color AR0521
  • MIPI CSI-2 interface
  • onsemi AR0521 1/2.5" 5MP color image sensor with ISP
  • M12 lens mount (S-mount)

ロードマップ

供給コミットメント
NXP社のロードマップによると
2034+


ハードウエア ロードマップ

このロードマップは、Toradexのハードウェア開発の観点から見た場合の製品計画を示しています。これは、リリースの日付を詳細に表すものではなく、Toradex社内の製品開発タイムラインを視覚化したものです。

*ボリューム製品の状態になる前のバージョンは、予告なしに変更される場合がありますのでご注意ください。 Toradexは、サンプル製品の段階ではバージョンが更新される可能性があります。製品がボリューム製品のバージョンへ変更された後、安定した製品を提供しておりますが、万が一変更が御座います時は、可能な限り敏速にご連絡申し上げます。Toradexのフェーズオーバーポリシーの詳細については、PCNポリシーページを参照してください。

  • 2023年7月~9月
  • 2023年10月~12月
  • 2024年1月~3月
  • 2024年4月~6月
  • 2024年7月~9月
0037 Apalis iMX8QM 4GB WB IT

0047 Apalis iMX8QM 4GB IT

0048 Apalis iMX8QP 2GB WB

0049 Apalis iMX8QP 2GB

0067 Apalis iMX8QM 8GB WB IT

  •
  • 開発中
  •
  • サンプル品
  •
  • 量産品



SWの現状

下記に最新情報がご覧頂けます
Linux BSP | Torizon OS BSP

...

すぐに使用可能、ドキュメント化済み、検証済み

動作するが、ドキュメント化と検証は未実施

将来的な機能、未検証 お問い合わせ

ご購入

5 コンピューターモジュール, 3 キャリアボード, 10 アクセサリー
V1.1A
Apalis iMX8QM
PN: 00671100

NXP® i.MX 8QuadMax, 2x Arm Cortex™-A72, 4x Arm Cortex™-A53, 1.6 GHz (A72), 1.26 GHz (A53), 266 MHz (M4), 8GB LPDDR4 (64 bit), 32GB eMMC, Gigabit with AVB (+2nd RGMII) Ethernet, -40° to 85° C(1) Temp. Range, Availability until 2034+

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $375.00
    $360.00
    $337.50
    $322.50
現在在庫僅少です。詳しくは お問い合わせ からお尋ねください。

The power consumption is subject to variation, depending on the situation. Our estimation of the minimum and maximum power consumption is based on the lowest idle power consumption and the highest power consumption values during maximum load. Refer our developer article for more information.

使用目的: For End Products
V1.1E
Apalis iMX8QM
PN: 00371104

NXP® i.MX 8QuadMax, 2x Arm Cortex™-A72, 4x Arm Cortex™-A53, 1.6 GHz (A72), 1.26 GHz (A53), 266 MHz (M4), 4GB LPDDR4 (64 Bit), 32GB eMMC, Gigabit with AVB (+2nd RGMII) Ethernet, -40° to 85° C(1) Temp. Range, Availability until 2034+

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $324.85
    $311.85
    $292.35
    $279.35

The power consumption is subject to variation, depending on the situation. Our estimation of the minimum and maximum power consumption is based on the lowest idle power consumption and the highest power consumption values during maximum load. Refer our developer article for more information.

(1) The Wi-Fi/Bluetooth module featured on the SoM is rated for an operating temperature range of -30°C to +85°C. As this component is not deemed boot-critical, the SoM is still listed as an industrial temperature range product.

使用目的: For End Products
V1.1D
Apalis iMX8QM
PN: 00471103
Volume Production

NXP® i.MX 8QuadMax, 2x Arm Cortex™-A72, 4x Arm Cortex™-A53, 1.6 GHz (A72), 1.26 GHz (A53), 266 MHz (M4), 4GB LPDDR4 (64 Bit), 32GB eMMC, Gigabit with AVB (+2nd RGMII) Ethernet, -40° to 85° C Temp. Range, Availability until 2034+

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $299.90
    $287.90
    $269.90
    $257.90
使用目的: For End Products
V1.1D
Apalis iMX8QM
PN: 00481103

NXP® i.MX 8QuadPlus, 1x Arm Cortex™-A72, 4x Arm Cortex™-A53, 1.6 GHz (A72), 1.26 GHz (A53), 266 MHz (M4), 2GB LPDDR4 (64 Bit), 32GB eMMC, Gigabit with AVB (+2nd RGMII) Ethernet, -25° to 85° C Temp. Range, Availability until 2034+

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $268.75
    $258.00
    $241.90
    $231.15
現在在庫僅少です。詳しくは お問い合わせ からお尋ねください。
使用目的: For End Products
V1.1D
Apalis iMX8QM
PN: 00491103
Volume Production

NXP® i.MX 8QuadPlus, 1x Arm Cortex™-A72, 4x Arm Cortex™-A53, 1.6 GHz (A72), 1.26 GHz (A53), 266 MHz (M4), 2GB LPDDR4 (64 Bit), 32GB eMMC, Gigabit with AVB (+2nd RGMII) Ethernet, -25° to 85° C Temp. Range, Availability until 2034+

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $243.45
    $233.75
    $219.15
    $209.40
現在在庫僅少です。詳しくは お問い合わせ からお尋ねください。
使用目的: For End Products
V1.2A

Small form-factor Apalis Arm Computer Module family Carrier Board

Connectivity: USB 3.0: 2x Host, USB 2.0: 1x Host/ 1x OTG, Gigabit Ethernet, 2x I2C, 1x SPI, 4x PWM, 4x ADC, 2x CAN, 2x LEDs, up to 40 GPIOs

Multimedia: Audio out: 1x (Stereo), Audio in: 1x (Stereo), 1x/ 1x S/PDIF In/ Out, 1x 10 Bit Camera Parallel Interface, 4/5-wire Resistive Touch

Physical: 7-27V DC Supply Voltage, 5V 6A, 3.3V 8A On-Board Power Supplies, Size: 125 x 90 mm

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $131.25
    $126.00
    $118.15
    $112.90
使用目的: For End Products
V1.3A
Ixora キャリアボード V1.3A
PN: 01331300

Small form-factor Apalis Arm Computer Module family Carrier Board

Connectivity: USB 3.0: 2x Host, USB 2.0: 1x Host/ 1x OTG, Gigabit Ethernet, 2x I2C, 1x SPI, 4x PWM, 4x ADC, 2x CAN, 2x LEDs, up to 40 GPIOs

Multimedia: Audio out: 1x (Stereo), Audio in: 1x (Stereo), 1x/ 1x S/PDIF In/ Out, 1x 10 Bit Camera Parallel Interface, 4/5-wire Resistive Touch

Physical: 7-27V DC Supply Voltage, 5V 6A, 3.3V 8A On-Board Power Supplies, Size: 125 x 90 mm

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $131.25
    $126.00
    $118.15
    $112.90
現在在庫僅少です。詳しくは お問い合わせ からお尋ねください。
使用目的: For End Products
V1.1Z
Apalis 評価ボード V1.1Z
PN: 01151125
Sample Production

Connectivity: USB 3.0: 1x Host, 1x OTG, USB 2.0: 4x Host, Gigabit Ethernet, 3x I2C, 2x SPI, 4x PWM, 4x ADC, 2x CAN, 8x Switches, 8x LEDs, up to 135 GPIOs

Multimedia: Audio out: 1x (Stereo), Audio in: 1x (Stereo), 1x (Out also on TOSLINK) S/PDIF In/ Out, 1x 8/10/12 Bit Camera Parallel Interface, 4/5-wire Resistive Touch

Physical: 7-27V DC Supply Voltage, 5V 5A, 3.3V 5A On-Board Power Supplies, Size: 250 x 250 mm

  • 数量
    >0
  • 単価
    $325.00
現在在庫僅少です。詳しくは お問い合わせ からお尋ねください。
使用目的: For Evaluation/Development
V1.0B
Apalis Heatsink Type 4
PN: 23081001
Volume Production

Heatsink for Apalis iMX8 modules

Compatible with Apalis iMX8. Easily mounted to the Apalis Carrier Boards by means of 4 screws. Additional threaded holes available for attaching fan to the carrier board.

  • 数量
    1-99
    100-249
    250-499
    500-999
  • 単価
    $16.20
    $15.60
    $14.60
    $14.00
使用目的: For End Products
V1.1A
Apalis Heatsink Fan
PN: 23091100
Sample Production

Heatsink Fan is compatible with all Apalis Heatsink types and plug-and-play with Apalis Evaluation Board and Ixora Carrier board.

The fan is intended for development and evaluation purposes only.

Compatible with Apalis Evaluation Board and Ixora Carrier Board.

  • 数量
    >0
  • 単価
    $19.90
使用目的: For Evaluation/Development
V1.0A
Capacitive Touch Display 10.1
PN: 12121000

Capacitive Touch Displays (LVDS) for Apalis modules

LVDS cable (250mm) and 10 pin FFC cable (250mm) to connect it with a Carrier Board. -20° to 70° C Temp, Range. Size: 248.5 x 166.1 x 15.0 mm.

  • 数量
    >0
  • 単価
    $294.00
使用目的: For Evaluation/Development
V1.1C
キャリアボードアクセサリキット
PN: 01131102

Accessory kit for Toradex carrier boards

Power Adapter: 12VDC 30W with international plugs. Compatible with: Apalis Evaluation Board, Ixora Carrier Board, Colibri Evaluation Board, Iris Carrier Board, Verdin Development Board, Dahlia Carrier Board.

  • 数量
    >0
  • 単価
    $49.90
使用目的: For Evaluation/Development
V1.0A
PCB Antenna Unictron AA222 MHF4 100mm
PN: 21541000

Cable length: 100mm. Frequency bands: 2.4 GHz and 5 GHz (dual-band). Manufacturer: Unictron. Reference: AA222 (H2B1PD1A1C385L), Range. Size: 40.0 x 6.0 x 0.5 mm.

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $5.00
    $3.75
    $3.25
    $2.90
使用目的: For End Products
V1.0A
Chang Hong DA-2458-02 Dual-Band Wi-Fi/Bluetooth Dipole Antenna RP-SMA
PN: 21511000

Frequency bands: 2.4 GHz and 5 GHz (dual-band). Manufacturer: Chang Hong. Reference: DA-2458-02, Range. Size: 106.0 x 10.0 (max. diameter) mm.

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $6.00
    $4.50
    $3.90
    $3.45
使用目的: For End Products
V1.0A
Pigtail Antenna Cable MHF4 to RP-SMA 100mm and 200mm
PN: 21521000

Cable length: 100mm.

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $5.00
    $3.75
    $3.25
    $2.90
使用目的: For End Products
V1.0A
Pigtail Antenna Cable MHF4 to RP-SMA 100mm and 200mm
PN: 21531000

Cable length: 200mm.

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $6.00
    $4.50
    $3.90
    $3.45
使用目的: For End Products
V1.0A
Pigtail Antenna Cable MHF4 to RP-SMA 100mm and 200mm
PN: 21551000

Cable length: 200mm. Suitable for outdoor-usage (IP67).

  • 数量
    1-99
    100-249
    250-499
    500-999
    >999
  • 単価
    $8.00
    $6.00
    $5.20
    $4.60
使用目的: For End Products
V1.0A
CSI Camera Set 5MP Color AR0521
PN: 01641000

MIPI CSI-2 camera set based on the onsemi AR0521 image sensor

Key features:
  • MIPI CSI-2 interface
  • onsemi AR0521 1/2.5" 5MP color image sensor with ISP
  • M12 lens mount (S-mount)

MIPI CSI-2 interface. onsemi AR0521 1/2.5" 5MP color image sensor with ISP. M12 lens mount (S-mount). -20° to 60° C (limited by the included lens) Temp.

  • 数量
    >0
  • 単価
    $119.50
使用目的: For Evaluation/Development
Have a Question?
