5.7" TFT VGA with Touch Display for Apalis & Colibri modules
EDT 5.7" Display with 640x480px, 18-bit RGB, 4-Wire Resistive Touch, Unified TFT Interface from EDT, 250mm FFC cable, -10° to 60° C, Range. Size: 124.7 (W) x 100 (H) x 11.7 (D) (MAX) mm.
NXP®/Freescale i.MX 6 Computer on Module - Colibri iMX6
| Colibri iMX6 Datasheet | Rev. 1.6 | 2017-05-10 | 2.3 MB |
| Block Diagram | Size: 70.89 KB |
| Technical Details | Developer Website |
Powered by NXP®/Freescale i.MX 6: i.MX 6 DualLite and i.MX 6 Solo Processors
The Colibri iMX6 is a SODIMM sized computer module that comes in both dual core and single core versions with CPUs based on NXP/Freescale i.MX6DL and NXP/Freescale i.MX6S SoCs respectively. The Cortex A9 dual core and single core CPU peaks at 1 GHz for commercial temperature variant, while the industrial temperature variant has a peak frequency of 800 MHz.
The Colibri iMX6 incorporates DVFS (Dynamic Voltage and Frequency Scaling) and Thermal Throttling that enable the system to continuously adjust operating frequency and voltage in response to changes in workload and temperature to achieve the best performance with the lowest power consumption.
Suitable for wide range of Industrial Applications
The module targets a wide range of applications, including: Digital Signage, Medical Devices, Navigation, Industrial Automation, HMIs, Avionics, Entertainment system, POS, Data Acquisition, Thin Clients, Robotics, Gaming and much more.
It offers a wide range of interfaces from simple GPIOs, industry standard I2C, SPI, CAN, and UART buses through to high speed USB 2.0 interfaces and a 16/32bit external memory bus (parallel bus). The HDMI interface makes it very easy to connect large, full HD resolution displays.
Easy Performance Upgrade
This module is a member of the extensive pin-compatible Colibri family. So, existing customers using any module in the Colibri family can easily migrate to Colibri iMX6.
The Colibri iMX6 module encapsulates the complexity associated with modern day electronic design, such as high speed impedance controlled layouts with high component density utilising blind and buried via technology. This allows the customer to create a carrier board which implements the application specific electronics generally being much less complicated.
Latest Information on Colibri iMX6
You can find the latest information on Colibri iMX6 at the Toradex Developer Center.
Microsoft® Windows® Embedded Compact, formerly known as Windows CE, is an open, scalable, 32-bit operating system (OS) that integrates reliable, real time capabilities with advanced Windows technologies.
Windows Embedded Compact allows you to build a wide range of innovative, small footprint devices. A typical Windows Embedded Compact–based device is designed for a specific use, can easily be connected to networks (e.g. Internet), and requires a small OS that has a deterministic response to interrupts. They can run head-less but are also able to drive low to high resolution displays.
Examples include enterprise tools, such as industrial controllers, communications hubs, and point-of-sale terminals, and consumer products, such as cameras, Internet appliances, and interactive televisions.
| Windows CE 5.0 / 6.0 |
Windows Embedded Compact 7.0 | Windows Embedded Compact 2013 | |
| Overview | |||
| Toradex Products with included Run Time License |
Windows CE 5.0 / 6.0 Core Colibri PXA, Colibri Txx, Colibri VFxx, Colibri iMX6, Apalis T30, Apalis iMX6 |
Windows Embedded Compact 7.0 NR Colibri Txx, Colibri VFxx, Colibri iMX6, Colibri iMX7, Apalis T30, Apalis iMX6 |
Windows Embedded Compact 2013 Entry Colibri Txx, Colibri VFxx, Colibri iMX6, Colibri iMX7, Apalis T30, Apalis iMX6 |
| Toradex Products with Optimised BSP |
Colibri PXA, |
Colibri Txx, Colibri VFxx, Colibri iMX6, Apalis T30, Apalis iMX6 | Colibri T30, Colibri VFxx, Colibri iMX6, Apalis T30, Apalis iMX6 |
| Additional images from Toradex | |||
| Application Development Environment | Visual Studio 2008 | Visual Studio 2008 | Visual Studio 2013 |
| Minimum Availability of OS Support | 2022 | 2026 | 2028 |
| OS Feature Set (not all modules support all OS features, check individual module datasheet for details) |
|||
| Preemptive Multitasking | |||
| Support for Multi-Core | - | ||
| Protected Application Memory Space | |||
| Snapshot Boot | - | - | |
| Real Time Capabilities | |||
| Interrupt Latency <7 uS | |||
| .NET Compact Framework | Version 2.0 and 3.5 | Version 2.0 and 3.5 | Version 3.9 |
| Component Services: COM, DCOM | |||
| XML | |||
| Servers (DHCP, File, Telnet, FTP, HTTP, Time) | |||
| RAM Based Registry (alternative: hive based) | |||
| FAT / TFAT (Transaction Safe FAT) | |||
| exFAT | (1) | ||
| Power Management | |||
| DirectDraw Graphics Including Alpha Blending | |||
| Touch | |||
| Touch Gestures | - | ||
| Audio with Codecs | |||
| DirectShow and Video Codecs | |||
| 3D Acceleration | |||
| OpenGL ES V2.0 | - | ||
| USB: Storage Device, HID, RNDIS, ActiveSync | |||
| UART, LAN, TCP/IP | |||
| IrDA | - | - | |
| WLAN, Bluetooth | |||
| SDIO | |||
| SDSC, SDHC, SDXC Support (2) | |||
| Authentication Services: NTLM, SSL/TLS, Kerberos | |||
| Support for International Fonts and Languages | |||
| Toradex Software(3) | |||
| Colibri Tweak/Display Tool | |||
| GPIO Configurator | |||
| Bootloader and OS Update Tool | |||
| Application launcher | |||
| Easy Production Programming | |||
| Toradex Libraries (Cloud, GPIO, Interrupt, PWM, ADC, I2C, SPI, CAN, and more) |
| Example Third Party Software (4) | |||
| Software PLC | CODESYS (3S), ProConOS (KW) | ||
| Java VM | Creme (NSIcom) | ||
| Infotainment Framework | EB GUIDE (Elekrobit) | ||
| Java Programming System | Eve (Ewesoft.com) | ||
| Application Framework | Qt | ||
| Lab Automation Framework | LabVIEW (National Instruments) | ||
| HMI Framework | UI Composer (NVIDIA) | ||
| HTML5 Web Browser | Webkit Browser (Zetakey) | ||
| Silverlight for Windows Embedded | XAML In The Hand (In The Hand) | ||
Notes:
(1) Not WinCE 5.0
(2) The default file system on SDXC cards is exFAT, which is not supported by Windows CE5. Using SDXC cards is still possible with Windows CE5 when using other file system e.g. FAT32. Windows CE6 and Windows Embedded Compact 7 & 2013 support exFAT
(3) For complete list of tools, please refer WEC Tools & Utilities
(4) For more details on supported third party software, please refer to our Partner page
Linux is a Unix-like computer operating system assembled under the model of free and open source software development and distribution.
The advantage over proprietary embedded operating systems include a support base that is not restricted to the employees of a single software company, and the ability to modify and redistribute the source code.
| Overview | |||||
| Toradex Products with optimised BSP | Colibri T20/T30, Apalis T30 | Apalis TK1 | Colibri VF50/VF61 | Apalis iMX6/Colibri iMX6 | Colibri iMX7 |
| U-Boot Bootloader | 2016.11 | 2016.11 | 2016.11 | 2016.11 | 2016.11 |
| Linux Kernel | 3.1.10 | 3.10.40 | 4.4.59 | 4.1.39 | 4.1.39 |
| Codebase | NVIDIA L4T R16.5 | NVIDIA L4T R21.5 | Mainline kernel.org 4.4 LTS | FSL Community 4.1-2.0.x-imx incl. NXP®/Freescale 4.1.15 2.0.0 GA | FSL Community 4.1-2.0.x-imx incl. NXP®/Freescale 4.1.15 2.0.0 GA |
| Angstrom/OpenEmbedded/Yocto | 2016.12/morty/2.2 | 2016.12/morty/2.2 | 2016.12/morty/2.2 | 2016.12/morty/2.2 | 2016.12/morty/2.2 |
| U-Boot Bootloader | |||||
| Environment Storage | |||||
| Ethernet Download | |||||
| NAND (iMX7, T20, VF50 or VF61) / eMMC (iMX6, T30 or TK1) Flash | |||||
| RAM Size Auto Detection | |||||
| 115200 Baud Serial Debug Console | |||||
| Toradex Configuration Block Handling | |||||
| USB Storage as Host | |||||
| DFU or UMS as USB Device | tbd | ||||
| Kernel | |||||
| Preemptive Multitasking | |||||
| Symmetric Multiprocessing (SMP) | - | (iMX7D only, on A7 cores) | |||
| Heterogeneous Multi-Core (bare metal, FreeRTOS, eCos or uClinux on M4 core) | - | (K20 Companion MCU) | (VF61 only) | - | |
| Protected Application Memory Space | |||||
| Real Time Capabilities | |||||
| GPIOlib (/sys/class/gpio) | |||||
| Temperature Sensor CPU | |||||
| Temperature Sensor Board | - | tbd | |||
| eMMC Flash EXT3 | (T30 only) | - | - | ||
| NAND Flash MTD UBI/UBIFS | (T20 only) | - | - | ||
| Ethernet | |||||
| Serial Debug Console | |||||
| High Speed Serial | |||||
| I2C | |||||
| SPI | |||||
| MMC/SD Card | (Apalis T30 optional 8-bit) | (4-bit only) | (Apalis iMX6 optional 8 bit) | ||
| HDMI Audio | - | - | |||
| Analog Audio Capture and Playback | (VF61 only) | ||||
| Resistive Touch | |||||
| External Bus Interface | (Colibri only) | - | - | (Colibri only) | (16 Bit multiplexed only) |
| Framebuffer Console | |||||
| Custom Ethernet MAC Address | |||||
| Serial Number and Board Revision | |||||
| Watchdog | |||||
| USB OTG Port / Automatic USB Device / Host | |||||
| USB Device Ethernet RNDIS gadget | |||||
| USB Host Port(s) | |||||
| USB Classes: Audio/ HID / HID raw / Mass Storage / UVC Webcam | |||||
| PWM LEDs (/sys/class/leds or /sys/class/pwm) | |||||
| Analog Inputs | (1.8V only) | ||||
| Real Time Clock | |||||
| Power Management (DVFS / Thermal Throttling) | - | ||||
| Suspend LP1 | |||||
| Optional parallel Camera, ITU-R BT.656 Embedded Sync / external Sync | - | tbd | tbd | ||
| Optional 1-Wire | (bit-bang) | (bit-bang) | (bit-bang) | (bit-bang) | |
| Crypto Engine Support | tbd | tbd | |||
| GPIO Keys | tbd | ||||
| CAN | (Apalis only) | tbd | |||
| Additionally on Apalis | |||||
| Codec IF | HD Audio / I2S | HD Audio / I2S | AC97 / I2S | ||
| PCIe | |||||
| SATA | |||||
| Optional MIPI CSI Camera | |||||
| User Space | |||||
| LXDE Desktop Environment | |||||
| HDMI / DVI-D | - | - | |||
| Digital RGB / LVDS | (single channel LVDS only) | ||||
| CRT aka Internal Video DAC | - | - | - | - | |
| Gstreamer Audio/Video Codecs (see note 1) | - | - | |||
| Gstreamer Video Decode/Playback (see note 1) | (1080p) | (2160p) | - | (1080p) | - |
| Gstreamer Video Encoder (see note 1) | - | - | |||
| OpenGL | ES 1.1/2.0 | 4.4 and ES 3.1 | - | 2.1 and ES 3.0 | - |
| Web Browser | Firefox | Firefox | - | Firefox | Firefox |
| Toradex Software | |||||
| Resource Monitor | tbd | tbd | |||
| GPIO Tool | |||||
| Third Party Software | |||||
| GTK, Qt, OpenCV, CANopen, Perl, Python, Java and more | Most standard Linux packages can be cross-compiled and run without any issues | ||||
Note 1 - Customer is required to obtain the proper license / approval from the respective IP holder.
|
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| ×Colibri Evaluation Board | ×Iris Carrier Board | ×Orchid Carrier Board | ×Viola Carrier Board | ×Aster Carrier Board | |
 |  |  |  |  | |
| Datasheet | Datasheet | Datasheet | Datasheet | Datasheet | |
| detail... | detail... | detail... | detail... | detail... | |
| Connectivity | |||||
| Supported Modules | Entire Colibri Family | Entire Colibri Family | Entire Colibri Family | Entire Colibri Family | Entire Colibri Family |
| Compact Flash Card Interface | — | — | 1x | — | — |
| External Bus | Up to 32 Bit | — | — | — | — |
| USB | 4x Host (High Speed) 1x Device (High Speed) 1x OTG (High Speed) | 1x Host (High Speed) 1x OTG (High Speed) | 2x Host (Full Speed) 1x Device (Full Speed) | 2x Host (High Speed) 1x Client (Shared) / 2x Host (High Speed) | 2x (High Speed) 1x Device (High Speed) |
| I2C | up to 4x | 1x | 1x | 1x | 1x |
| SPI | up to 4x | 2x | 2x | 1x | 1x |
| UART | 2x RS232 1x RS422/485 | 3x RS232 | 1x RS232 / 2x RS232 | 3x | 2x TTL, 1x USB |
| IrDA | 1x | — | 1x | — | — |
| PWM | 4x | 4x | 4x | 4x | 4x |
| GPIO | up to 158 | up to 26 | up to 20 | up to 35 | up to 39 |
| Analog Input | 4x | 4x | 4x | 4x | 4x |
| Ethernet | 10/100 Mbit | 10/100 Mbit | 10/100 Mbit | 10/100 Mbit | 10/100 Mbit |
| SDIO/SD/MMC | 1x 4 Bit | 1x 4 Bit (microSD) | 1x 4 Bit | 1x 4 Bit (microSD) | 1x 4 Bit (Full Size) |
| CAN | 1x | — | — | 1x (Available with Colibri VFxx and iMX) | 1x (Available with Colibri VFxx and iMX) |
| Input / Output | |||||
| Switches | 6x | — | — | — | — |
| LEDs | 4x | — | — | — | up to 3x |
| Multimedia | |||||
| LVDS | 1x Single Channel | 1x Single Channel | — | — | — |
| HDMI | 1x (Through DVI-I connector) | 1x (Through DVI-I connector) | — | — | — |
| VGA | 1x | 1x (Through DVI-I connector) | 1x | — | 1x (Shared with RGB) |
| RGB | 1x (18 Bit/24 Bit) | 1x (18 bit) | 1x (18 Bit) | 1x (18 Bit) | 1x |
| Resistive Touch | 4/5-wire | 4/5-wire | 4-wire | 4-wire | 1x / 1x |
| Camera Parallel Interface | 1x | — | — | 1x / — | — |
| Analog Audio Line in | 1x (Stereo) | 1x (Stereo) | — / 1x (Stereo) | 1x (Stereo) / — | 1x (Stereo) |
| Analog Audio Mic in | 1x (Mono) | 1x (Mono) | 1x (Mono) | 1x (Mono) / — | 1x (Mono) |
| Analog Audio Headphone out | 1x (Stereo) | 1x (Stereo) | 1x (Stereo) | 1x (Stereo) / — | 1x (Stereo) |
| Other | |||||
| USB-to-RS232 Transceiver | 1x | — | — | — | 1x |
| RTC on Board | 1x | 1x | 1x | 1x / 1x (*Not Assembled) | — |
| Included Accessory | Mating Power Plug (for X33) 24-way FFC 100mm (for X6) | Mating Power Plug (for X17) 24-way FFC 35mm (for X4) | Mating Power Plug (for X5) | — | — |
| Altium CAE Data Freely Available | Yes | Yes | — | Yes | Yes |
| JTAG | Yes | — | — | — | Yes |
| Physical | |||||
| Supply Voltage | 7-27V DC | 6-27V DC | 7-24V DC | 5V DC | 5V DC |
| On-Board Power Supplies | 5V 5A 3.3V 5A | 5V 5A 3.3V 5A | 5V 5A 3.3V 5A | 5V (External) 3.3V 3A | 3.3V 3A |
| Size | 200 x 200 mm | 100 x 72 mm | 160 x 100 mm | 74 x 74 mm | 100 x 80 mm |
| Temperature | — | -10° to +70° C -20° to +85° C | -30° to +85° C | -40° to +85° C / -40° to +85 °C | -25° to +85° C |
7.0" TFT WVGA with Touch Display for Apalis & Colibri modules
EDT 7" Display with 800x480px, 18-bit RGB, 4-Wire Resistive Touch, Unified TFT Interface from EDT, 250mm FFC cable, -20° to 70° C, Range. Size: 166 (W) x 105.44 (H) x 10.95 (D) (max) mm.
LVDS converters for Colibri modules
18-bit RGB to LVDS, 1mm pitch, Compatible with various Toradex carrier boards.
LVDS converters for Colibri modules
18-bit RGB to LVDS, 1.25mm pitch, Compatible with various Toradex carrier boards.
Fasteners for Colibri modules
Proven reliability in many vibration and shock tests, Colibri carrier boards provide mounting holes (except for Viola), 1 Fastener bag contains 100 Fasteners.
10" Multi-Touch Display kit for Apalis & Colibri modules
Fusion 10" Display with 1024x600px, Capacitive Multi-Touch, Interface Board for easy connection, Display signals over RGB-TTL, Drivers for Linux and WinCE.
Accessory kit for Toradex carrier boards
Cables: USB, Ethernet, RS232, Jumper Wires, Adapters: DVI to VGA, HDMI to DVI, USB to RS232, USB Micro-A to A (USB Micro-AB receptacle to Type A), RS232 Header to D-Sub, Iris Power-adapter, Power Adapter: 12VDC 30W with international plugs, Compatible with: Apalis Evaluation Board, Ixora Carrier Board, Colibri Evaluation Board, Iris Carrier Board.
HDMI Adapter for Colibri modules
Compatible with Colibri T20, Colibri T30 and Colibri iMX6, Provides easy-to-use interface to connect a full HD monitor to the Colibri Module using HDMI interface, No external power supply required.
LM006 USB WiFi for Apalis and Colibri Family
Operates in 2.4 GHz frequency bands with data rate up-to 150 Mbps, 1×1 SISO technology improves effective throughput and range over existing 802.11 b/g products, 802.11e-compatible bursting and I standards, BPSK, QPSK, 16 QAM, 64 QAM modulation schemes, WEP, TKIP, AES, WPA and WPA2 hardware encryption schemes, Can be setup as a ad-hoc network via peer to peer communications.
Analogue Camera Adapter for Apalis & Colibri modules
Uses Analog Devices, ADV7280 video decoder, Analogue Camera Input : 4 multiplexed video input channels, supporting NTSC / PAL / SECAM composite video signals, Parallel data output format: 8-Bit Parallel ITU-R BT.656 with external HSync and VSync, No external power supply required, Compatible with Colibri Evaluation Board and Apalis Evaluation Board.
- EDT 5.7" Display with 640x480px
- 18-bit RGB
- 4-Wire Resistive Touch
- Unified TFT Interface from EDT
- 250mm FFC cable
- -10° to 60° C
- EDT 7" Display with 800x480px
- 18-bit RGB
- 4-Wire Resistive Touch
- Unified TFT Interface from EDT
- 250mm FFC cable
- -20° to 70° C
- 18-bit RGB to LVDS
- 1mm pitch
- Compatible with various Toradex carrier boards
- 18-bit RGB to LVDS
- 1.25mm pitch
- Compatible with various Toradex carrier boards
- Proven reliability in many vibration and shock tests
- Colibri carrier boards provide mounting holes (except for Viola)
- 1 Fastener bag contains 100 Fasteners
- Fusion 10" Display with 1024x600px
- Capacitive Multi-Touch
- Interface Board for easy connection
- Display signals over RGB-TTL
- Drivers for Linux and WinCE
- Cables: USB, Ethernet, RS232, Jumper Wires
- Adapters: DVI to VGA, HDMI to DVI, USB to RS232, USB Micro-A to A (USB Micro-AB receptacle to Type A), RS232 Header to D-Sub, Iris Power-adapter
- Power Adapter: 12VDC 30W with international plugs
- Compatible with: Apalis Evaluation Board, Ixora Carrier Board, Colibri Evaluation Board, Iris Carrier Board
- Compatible with Colibri T20, Colibri T30 and Colibri iMX6
- Provides easy-to-use interface to connect a full HD monitor to the Colibri Module using HDMI interface
- No external power supply required
- Operates in 2.4 GHz frequency bands with data rate up-to 150 Mbps
- 1×1 SISO technology improves effective throughput and range over existing 802.11 b/g products
- 802.11e-compatible bursting and I standards
- BPSK, QPSK, 16 QAM, 64 QAM modulation schemes
- WEP, TKIP, AES, WPA and WPA2 hardware encryption schemes
- Can be setup as a ad-hoc network via peer to peer communications
- Uses Analog Devices, ADV7280 video decoder
- Analogue Camera Input : 4 multiplexed video input channels, supporting NTSC / PAL / SECAM composite video signals
- Parallel data output format: 8-Bit Parallel ITU-R BT.656 with external HSync and VSync
- No external power supply required
- Compatible with Colibri Evaluation Board and Apalis Evaluation Board
6 Modules, 7 Carrier Boards, 9 Accessories
PN: 00151000
Colibri iMX6 DualLite 512MB | V1.0A
NXP®/Freescale i.MX 6DualLite, ARM Cortex™-A9, 1.0 GHz, Dual Core, 512MB DDR3 (64 Bit), 4GB eMMC (8 Bit), 10/100 Mbit IEEE1588 Ethernet, 0° to 70° C Temp. Range, Availability until 2028
|
|
in stock
PN: 00171001
Colibri iMX6 DualLite 512MB IT | V1.0B
NXP®/Freescale i.MX 6DualLite, ARM Cortex™-A9, 800 MHz, Dual Core, 512MB DDR3 (64 Bit), 4GB eMMC (8 Bit), 10/100 Mbit IEEE1588 Ethernet, -40° to +85° C Temp. Range, Availability until 2028
|
|
low stock
Currently low stock level. More coming soon. Please contact us for details.
PN: 00171100
Colibri iMX6 DualLite 512MB IT | V1.1A
NXP®/Freescale i.MX 6DualLite, ARM Cortex™-A9, 800 MHz, Dual Core, 512MB DDR3 (64 Bit), 4GB eMMC (8 Bit), 10/100 Mbit IEEE1588 Ethernet, -40° to +85° C Temp. Range, Availability until 2028
|
|
low stock
Currently low stock level. More coming soon. Please contact us for details.
PN: 00141000
Colibri iMX6 Solo 256MB | V1.0A
NXP®/Freescale i.MX 6Solo, ARM Cortex™-A9, 1.0 GHz, Single Core, 256MB DDR3 (32 Bit), 4GB eMMC (8 Bit), 10/100 Mbit IEEE1588 Ethernet, 0° to 70° C Temp. Range, Availability until 2028
|
|
in stock
PN: 00161001
Colibri iMX6 Solo 256MB IT | V1.0B
NXP®/Freescale i.MX 6Solo, ARM Cortex™-A9, 800 MHz, Single Core, 256MB DDR3 (32 Bit), 4GB eMMC (8 Bit), 10/100 Mbit IEEE1588 Ethernet, -40° to +85° C Temp. Range, Availability until 2028
|
|
low stock
Currently low stock level. More coming soon. Please contact us for details.
PN: 00161100
Colibri iMX6 Solo 256MB IT | V1.1A
NXP®/Freescale i.MX 6Solo, ARM Cortex™-A9, 800 MHz, Single Core, 256MB DDR3 (32 Bit), 4GB eMMC (8 Bit), 10/100 Mbit IEEE1588 Ethernet, -40° to +85° C Temp. Range, Availability until 2028
|
|
low stock
Currently low stock level. More coming soon. Please contact us for details.
100791009526149dd4-1f4d-11e7-be3b-9e9dd95319f81007810094b4d16a6a-2ef2-11e7-be3b-9e9dd95319f8
PN: 01013201
Colibri Evaluation Board | V3.2B
Connectivity: USB: 4x Host (High Speed)
1x Device (High Speed)
1x OTG (High Speed), 10/100 Mbit Ethernet, up to 4x I2C, up to 4x SPI, 4x PWM, 4x ADC, 1x CAN, 6x Switches, 4x LEDs, up to 158 GPIOs
Multimedia: Audio out: 1x (Stereo), Audio in: 1x (Stereo), 1x Camera Parallel Interface, 4/5-wire Resistive Touch
Physical: 7-27V DC Supply Voltage, 5V 5A
3.3V 5A On-Board Power Supplies, Size: 200 x 200 mm
|
|
in stock
PN: 01031001
Orchid Carrier Board | V1.0B
This product is only recommended for Colibri PXA modules
Connectivity: USB: 2x Host (Full Speed)
1x Device (Full Speed), 10/100 Mbit Ethernet, 1x I2C, 2x SPI, 4x PWM, 4x ADC, up to 20 GPIOs
Multimedia: Audio out: 1x (Stereo), Audio in: 1x (Stereo), 4-wire Resistive Touch
Physical: 7-24V DC Supply Voltage, 5V 5A
3.3V 5A On-Board Power Supplies, Size: 160 x 100 mm
|
|
in stock
PN: 01021002
Orchid Carrier Board | V1.0C
This product is only recommended for Colibri PXA modules
Connectivity: USB: 2x Host (Full Speed)
1x Device (Full Speed), 10/100 Mbit Ethernet, 1x I2C, 2x SPI, 4x PWM, 4x ADC, up to 20 GPIOs
Multimedia: Audio out: 1x (Stereo), 4-wire Resistive Touch
Physical: 7-24V DC Supply Voltage, 5V 5A
3.3V 5A On-Board Power Supplies, Size: 160 x 100 mm
|
|
in stock
PN: 01351101
Iris Carrier Board | V1.1B
Small form-factor Pico-ITX Colibri ARM Computer Module family Carrier Board
Connectivity: USB: 1x Host (High Speed)
1x OTG (High Speed), 10/100 Mbit Ethernet, 1x I2C, 2x SPI, 4x PWM, 4x ADC, up to 26 GPIOs
Multimedia: Audio out: 1x (Stereo), Audio in: 1x (Stereo), 4/5-wire Resistive Touch
Physical: 6-27V DC Supply Voltage, 5V 5A
3.3V 5A On-Board Power Supplies, Size: 100 x 72 mm
|
|
low stock
Currently low stock level. More coming soon. Please contact us for details.
PN: 01371200
Viola Carrier Board | V1.2A
Connectivity: USB: 2x Host (High Speed), 10/100 Mbit Ethernet, 1x I2C, 1x SPI, 4x PWM, 4x ADC, 1x (Available with Colibri VFxx and iMX) CAN, up to 35 GPIOs
Multimedia: 4-wire Resistive Touch
Physical: 5V DC Supply Voltage, 5V (External)
3.3V 3A On-Board Power Supplies, Size: 74 x 74 mm
|
|
in stock
PN: 01421200
Viola Plus Carrier Board | V1.2A Plus
Connectivity: USB: 2x Host (High Speed)
1x Client (Shared), 10/100 Mbit Ethernet, 1x I2C, 1x SPI, 4x PWM, 4x ADC, 1x (Available with Colibri VFxx and iMX) CAN, up to 35 GPIOs
Multimedia: Audio out: 1x (Stereo), Audio in: 1x (Stereo), 1x Camera Parallel Interface, 4-wire Resistive Touch
Physical: 5V DC Supply Voltage, 5V (External)
3.3V 3A On-Board Power Supplies, Size: 74 x 74 mm
|
|
in stock
PN: 01431101
Aster Carrier Board | V1.1B
Small form-factor with header compatible with Arduino Uno and Raspberry Pi (RPi) maker boards
Connectivity: USB: 2x (High Speed)
1x Device (High Speed), 10/100 Mbit Ethernet, 1x I2C, 1x SPI, 4x PWM, 4x ADC, 1x (Available with Colibri VFxx and iMX) CAN, up to 3x LEDs, up to 39 GPIOs
Multimedia: Audio out: 1x (Stereo), Audio in: 1x (Stereo), 1x Resistive Touch
Physical: 5V DC Supply Voltage, 3.3V 3A On-Board Power Supplies, Size: 100 x 80 mm
|
|
in stock
10113100161001504c0f319-45d5-11e7-9252-9e9dd95319f81010210108ba71d8c5-f1c8-11e6-be3b-9e9dd95319f8
PN: 01112000
Colibri Fasteners | V2.0A
Fasteners for Colibri modules
Proven reliability in many vibration and shock tests, Colibri carrier boards provide mounting holes (except for Viola), 1 Fastener bag contains 100 Fasteners.
|
|
in stock
PN: 12031000
Display EDT 5.7" | V1.0A
5.7" TFT VGA with Touch Display for Apalis & Colibri modules
EDT 5.7" Display with 640x480px, 18-bit RGB, 4-Wire Resistive Touch, Unified TFT Interface from EDT, 250mm FFC cable, -10° to 60° C, Range. Size: 124.7 (W) x 100 (H) x 11.7 (D) (MAX) mm.
|
|
in stock
PN: 12041000
Display EDT 7.0" | V1.0A
7.0" TFT WVGA with Touch Display for Apalis & Colibri modules
EDT 7" Display with 800x480px, 18-bit RGB, 4-Wire Resistive Touch, Unified TFT Interface from EDT, 250mm FFC cable, -20° to 70° C, Range. Size: 166 (W) x 105.44 (H) x 10.95 (D) (max) mm.
|
|
low stock
Currently low stock level. More coming soon. Please contact us for details.
PN: 01141000
Colibri HDMI Adapter | V1.0A
HDMI Adapter for Colibri modules
Compatible with Colibri T20, Colibri T30 and Colibri iMX6, Provides easy-to-use interface to connect a full HD monitor to the Colibri Module using HDMI interface, No external power supply required.
|
|
in stock
PN: 21031000
LM006 USB WiFi | V1.0A
LM006 USB WiFi for Apalis and Colibri Family
Operates in 2.4 GHz frequency bands with data rate up-to 150 Mbps, 1×1 SISO technology improves effective throughput and range over existing 802.11 b/g products, 802.11e-compatible bursting and I standards, BPSK, QPSK, 16 QAM, 64 QAM modulation schemes, WEP, TKIP, AES, WPA and WPA2 hardware encryption schemes, Can be setup as a ad-hoc network via peer to peer communications.
|
|
in stock
PN: 01192001
Analogue Camera Adapter | V2.0B
Analogue Camera Adapter for Apalis & Colibri modules
Uses Analog Devices, ADV7280 video decoder, Analogue Camera Input : 4 multiplexed video input channels, supporting NTSC / PAL / SECAM composite video signals, Parallel data output format: 8-Bit Parallel ITU-R BT.656 with external HSync and VSync, No external power supply required, Compatible with Colibri Evaluation Board and Apalis Evaluation Board.
|
|
in stock
PN: 01131100
Carrier Board Accessory Kit | V1.1A
Accessory kit for Toradex carrier boards
Cables: USB, Ethernet, RS232, Jumper Wires, Adapters: DVI to VGA, HDMI to DVI, USB to RS232, USB Micro-A to A (USB Micro-AB receptacle to Type A), RS232 Header to D-Sub, Iris Power-adapter, Power Adapter: 12VDC 30W with international plugs, Compatible with: Apalis Evaluation Board, Ixora Carrier Board, Colibri Evaluation Board, Iris Carrier Board.
|
|
in stock
PN: 01071001
LVDS Converter 1mm pitch | V1.0B
LVDS converters for Colibri modules
18-bit RGB to LVDS, 1mm pitch, Compatible with various Toradex carrier boards.
|
|
in stock
PN: 01081000
LVDS Converter 1.25mm pitch | V1.0A
LVDS converters for Colibri modules
18-bit RGB to LVDS, 1.25mm pitch, Compatible with various Toradex carrier boards.
|
|
in stock
10085100241002510091101038a52d8a9-afb3-11e6-be3b-9e9dd95319f80b6aecb5-12a3-11e7-be3b-9e9dd95319f81002810029
